EA-A Series Round Lifting Slings
The EA-A series round lifting slings are particularly suitable for lifting circular objects. Made of flexible, high-strength polyester industrial filaments with strong abrasion resistance, the load-bearing core is seamless, ensuring even stress distribution, long service life, and is lightweight and flexible, making it suitable for use in confined spaces. Complies with Chinese and European standard ENI492-2.
Send InquiryDetailed Description
1.Product Advantages
1. Particularly suitable for lifting circular objects.2. Flexible, high-strength polyester industrial filament; the sling is covered by an abrasion-resistant sheath made of polyester material, with markings indicating the approved specifications and tonnage. The sheath serves only a protective function.
3. The load-bearing core is a seamless, high-strength polyester fiber rope; the parallel arrangement of the polyester fibers provides the load-bearing capacity.
4. The flexible, high-strength polyester industrial filament sling uses international standard color-coded slings with clear load-bearing markings.
5. The sling distributes stress evenly, thus extending its service life.
6. Lightweight and flexible, suitable for use in confined spaces.
7.Complies with European standard EN1492-2:2000 and Chinese industry standard JB/T8521-2007.
2.Specification
|
Lift strap model |
color |
bundled lifting force |
Combined pulling force |
Approximate width(mm) |
Minimum length (m) |
Maximum length(m) |
| 1.0 | 0.8 | |||||
|
EA-A-01 |
Purple |
1000 |
800 | 50 |
1 |
100 |
|
EA-A-02 |
green |
2000 |
1600 | 60 |
1 |
100 |
|
EA-A-03 |
yellow |
3000 |
2400 | 70 |
1 |
100 |
|
EA-A-04 |
gray |
4000 |
3200 | 75 |
1 |
100 |
|
EA-A-05 |
red |
5000 |
4000 | 80 |
1 |
100 |
|
EA-A-06 |
brown |
6000 |
4800 | 90 |
1 |
100 |
|
EA-A-08 |
blue |
8000 |
6400 | 100 |
1 |
100 |
|
EA-A-010 |
orange |
10000 |
8000 | 110 |
1 |
100 |
|
EA-A-012 |
orange |
12000 |
9600 | 125 |
1 |
100 |
|
EA-A-015 |
blue |
15000 |
12000 | 150 |
1 |
100 |
